Operating Temperature up to 10,000 ft (3000 m):

23 to 104 F (-5 to 40 C)

Short-term Exception up to 13,000 feet (4000 m):

23 to 104 F (-5 to 40 C)

IPv4 IGMP Groups:

255

Model:

LAN Base Layer 2

MTBF:

336,409 hours

Power Rating:

0.075 kVA

Storage Altitude:

Up to 13,000 feet (4000 m)

Short-term Exception up to 10,000 feet (3000 m):

23 to 113 F (-5 to 45 C)

Packets per second (Mpps):

10.1

Weight:

8 lbs (3.6 kg)

Storage Temperature up to 15,000 feet (4573 m):

-13 to 158 F (-25 to 70 C)

Max. Watt Power Consumption:

45

Voltage:

100 to 240 VAC (Auto ranging); 50 to 60 Hz

Forwarding Bandwidth:

16 Gbps

Max. Watt Power:

45

Short-term Exception at Sea Level:

23 to 131 F (-5 to 55 C)

VLAN IDs:

4000

Rack Height:

1 RU

Operating Altitude:

Up to 10,000 feet (3000 m)

Uni cast MAC Addresses:

8000

Jumbo Frames:

9018 bytes

Flash Memory:

32 MB

Operating Relative Humidity:

10% to 95% non condensing

Operating Temperature up to 5000 ft (1500 m):

23 to 113 F (-5 to 45 C)

Memory DRAM:

64 MB

Max VLANs:

255

Storage Relative Humidity:

10% to 95% non condensing

Dimensions (H x W x D):

1.73 x 17.5 x 9.3 in. (4.4 x 44.5 x 23.6 cm.)

Power Consumption:

Measured 100% Throughput (with Max. PoE loads) of 162

AC/DC Support:

AC only

DC input voltages (RPS input):

12 V at 5 A

Maximum Transmission Unit (MTU):

Up to 9000 bytes

Short-term Exception up to 5000 feet (1500 m):

23 to 122 F (-5 to 50 C)

Up links:

2 dual-purpose ports (10/100/1000 or SFP) - each dual-purpose up link port has 1 10/100/1000 Ethernet port and 1 SFP-based Gigabit Ethernet port, 1 port active

Switching Bandwidth:

32 Gbps

Ports:

48 Ethernet 10/100 ports
